Newton HydroCoat 103 2K is a high performance cementitious waterproof coating with high adhesion that can be applied very quickly by airless spray. For reservoirs, water tanks, below ground structures, podium decks, balconies and parking areas.
Capable of resisting extremely high positive and negative water pressure, HydroCoat 103 2K forms a hard, highly alkaline coating with a degree of elasticity which has greatly enhanced chemical resistance and so is particularly suited for the protection of concrete within sulphate contaminated ground.
It has excellent resistance to the ingress of acid gases, moisture and chlorides to enhance the durability of reinforced concrete and protect highway and coastal structures from chloride attack. HydroCoat 103 2K is reinforced over static joints and at details and changes of direction with HydroCoat 912-RT.
Key Benefits:
- Very waterproof – Resistant to 10 bar positive and negative pressure.
- Quick application in one coat to horizontal surfaces.
- Non-toxic when cured.
- Sprayable – Up to 2 m2 per minute is possible.
- Hard, durable and UV-stable trafficable finish.
- All year round application to damp substrate.
- Can be applied at temperatures as low as 5°C.
- Very low VOC content.
- Very high diffusion resistance to carbon dioxide gas and chloride ions; equivalent to 100 mm of concrete cover.
- Excellent adhesion to sound prepared concrete substrates and steel.
- Thixotropic – can be applied at 1 mm to vertical surfaces.
- High build coating of 2 mm eliminates the incidence of small defects seen within thinner membranes.
Typical Waterproofing Applications:
- Podium decks, balconies and car parking areas.
- Concrete water-retaining structures such as water tanks and reservoirs.
- Concrete earth-retaining foundation walls to both the positive and negative side.
- Internal concrete surfaces of walls and rafts or slabs to earth-retained structures such as habitable basements, car parks, plant rooms and lift-pits.
- Concrete temporary lay down and working areas.
| Features |
Result |
Units |
| Form |
Part A liquid + Part B powder |
|
| Colour |
Grey |
|
| Mixed density |
1.950 |
|
| Pack size |
30 |
kg |
| Yield per pack |
15.4 |
Litres |
| Shelf life |
12 |
Months |
| Pot life @ 20ºC & RH of 40% |
30 |
Minutes |
| Application rate – in one or two coats |
3.9 |
kg/m2 |
| Application temperature |
+5 to +35 |
ºC |
| Service temperature |
-15 to +180 |
ºC |
| Odour |
Low – Characterised as polymeric |
|
| VOC content |
0 |
% |
| Curing* |
5ºC |
10ºC |
15ºC |
20ºC |
25ºC |
Units |
| Ready for next coat |
80 |
60 |
50 |
40 |
33 |
Minutes |
| To not be adulterated by rain |
3 |
2.5 |
2 |
1.5 |
1.5 |
Hours |
| Ready for temporary traffic/protection boards |
24 |
24 |
22 |
20 |
18 |
Hours |
| Ready for flood/hosepipe test |
8 |
7 |
6 |
5 |
4 |
Days |
| Fully cured |
28 |
28 |
28 |
28 |
28 |
Days |
| Cured Performance |
Result |
Units |
Test Method |
| Colour |
Grey |
|
|
| Membrane thickness in one or two coats |
2.0 |
mm |
|
| Adhesion to concrete |
2.07 |
MPa |
BS EN 1542 |
| Tensile strength |
2.66 |
MPa |
BS 6319-7:1994 |
| Static crack bridging capability (Class A2) |
0.4 |
mm |
BS EN 1062-7 – Method A |
| Dynamic crack bridging capability |
Not classified |
|
BS EN 1062-7 – Method B |
| Compressive strength – 1 day |
>10 |
MPa |
BS 4551 |
| Compressive strength – 7 days |
>30 |
MPa |
BS 4551 |
| Compressive strength – 28 days |
>40 |
MPa |
EN 12190 & BS 4551 |
| Hardness (28 days) |
>75 |
Shore D |
BS EN ISO 868:2003 |
| Water vapour resistance – SD value |
0.91 |
m |
BS EN ISO 7783-2 |
| Water vapour resistance – µ value |
455 |
µ |
Calculation from SD value |
| Water vapour resistance |
4.55 |
MNs/g |
Calculation from SD value |
| Water resistance – Positive & Negative |
10 |
Bar |
DIN 1048 |
| Liquid Water Transmission Rate (Capillary Absorption and Permeability to Liquid water) |
w = 0.018 kg.m-².h-⁰.⁵ |
|
EN1062-3 |
| Chloride Ion Diffusion Resistance |
No steady state of flux reached after 31 years on test |
|
Vinci Technology |
| Permeability to CO² |
50*** |
m |
EN 1062-6 |
| Thermal compatibility |
3.5 |
MPa |
EN 13687-1 |
| Coefficient of Thermal Expansion |
16.6 x 10-⁶K-¹ |
|
EN1770 |
| Reaction to fire classification |
A2-s1, d0 |
Euroclass |
BS EN 13501-1 |
| Wear Resistance |
Exceeds BCA AR0,5: Highest classification of wear resistance. |
|
EN13813 |
| UV Resistance – Stable but will discolour |
50 |
Years |
UNI EN ISO 11507:2007** |
| pH |
12-14 |
|
|
The above data, even if carried out according to regulated tests are indicative and they may change when specific site conditions vary.
*Figures are influenced by humidity also and so are indicative. **UNI EN ISO 11507:2007 is an accelerated ageing test. The result of 1000 hours translates to 50 years.
***2mm equivalent to 100mm of concrete.
