Flexible Construction Joint Waterproofing. Newton FlexProof 106 NV is a highly advanced, single-component liquid waterproofing material, which forms an elastomeric polymer membrane that is rainproof in minutes and capable of handling severe building movements and deformations.
The FlexProof 106 System is composed of two variants of the product, plus ancillaries:
- X1 – A thixotropic variant that is applied as a paste and so is suitable as a surface sealant over joints.
- NV – A lower viscosity variant that can be poured and is typically used within movement joints.
- FlexProof 106 Primer (Product code: 916) – Improves adhesion to porous surfaces.
- FoamStop (Product codes: FS1 to FS8) – Foam backing rod for movement joints.
- The animation to the right shows the correct application of FlexProof 106-X1 to a concrete construction joint.
Key Benefits:
- No mixing required – simply open the packaging and use.
- Can be used in sub-zero temperatures and on slightly damp substrate.
- No primer required – saving on primer and labour costs.
- 100% waterproof, but allows vapour diffusion.
- Very flexible – Resistant to movement and fissures in substrate.
- Excellent adhesion to suitable substrates.
- Resistant to temperature variations maintaining its characteristics between -40ºC & 90ºC.
- Excellent resistance to the high alkalinity of concrete.
Suitable For:
- FlexProof 106 X1 – Static construction joints in poured concrete retained structures.
- FlexProof 106 NV – Non-static construction joints to precast concrete elements within retained structures.
| Features |
Result |
Units |
| Form (paste) |
Low viscosity |
|
| Colour |
Grey |
|
| Density / Specific gravity |
1.44 |
|
| Packaging – foil bag within bucket |
7.5 |
kg |
| Packaging – cartridge |
N/A |
ml |
| Shelf life |
12 |
Months |
| Pot life |
6 |
Months |
| Application rate – over joints |
N/A |
kg/m2 |
| Application rate – not to joints |
3.0 |
kg/m² |
| Application rate – movement joints |
Depth of 50% of the joint width |
|
| Application method |
Trowel/putty knife. Brush for detailing |
|
| Minimum application temperature – substrate* |
+1 (and rising) |
ºC |
| Maximum application temperature – air |
+35 |
ºC |
| Service temperature |
-40 to +90 |
ºC |
| Odour |
Slight polymer |
|
| VOC |
None |
|
| Curing* |
5ºC |
10ºC |
15ºC |
20ºC |
25ºC |
Units |
| To not be adulterated by light rain |
15 |
12 |
10 |
10 |
5 |
Minutes |
| To not be adulterated by heavy rain |
20 |
17 |
15 |
15 |
10 |
Minutes |
| Ready for protection boards |
30 |
27 |
25 |
25 |
20 |
Minutes |
| Fully cured |
5 |
4 |
4 |
3 |
3 |
Days |
| Cured Performance |
Result |
Units |
Test Method |
| Colour |
Grey |
|
|
| Membrane thickness – over joints |
N/A |
mm |
|
| Membrane thickness – not over joints |
2.0 |
mm |
|
| Adhesion to concrete |
>450 |
KPa |
EOTA TR-003 |
| Tensile strength |
1.60 |
N/mm² |
BS EN 13813:2002 |
| Elasticity when breaking – 2 mm film |
450 |
% |
DIN EN 12311-2 |
| Resistance to dilute acid/alkaline |
Excellent |
|
DIN EN 1928 |
| Shore Hardness – A |
40 |
|
|
| Watertightness |
See data table on page 4 |
|
DIN EN 1928 |
| UV Resistance** |
10 |
Years |
EN ISO 11431:2002 |
| Reaction to fire classification – Euroclass |
E |
|
DIN EN 13501-1 |
The above data, even if carried out according to regulated tests are indicative and may change when specific site conditions vary. *Figures are for 2.5 mm coating and are influenced by humidity and are therefore, indicative.
** EN ISO 11431:2002 specifies a method for the determination of the adhesion/cohesion properties of sealants after cyclic exposure to heat and artificial light followed by a period of exposure to water at a defined temperature. The 10-year figure is an extrapolation of the results of these tests. The product may weather to with a slight yellow tint, but the product itself will not be affected.
